Features
- Load rated.
- Choice of fixed or swivel head models.
- Durable, low friction Acetal polymer sheave.
- RZ1611 has a cleating angle of 60∞ from the mounting plain and is ideal for ëremoteí operation as in the case of a ground based assistant raising tools or equipment to an overhead linesman.

Construction
- UV stabilised Acetal sheaves.
- Grade 316 stainless steel side plate/cheeks, powder coated black.
- Fibre reinforced polymer rope cleats.
- Grade 316 stainless steel head, shackle & becket.


- Sheave Diam: 60mm
- Max Rope: 12mm
- Pin Diam: 6mm
- M.W.L.: 1000kg *
- B.L.: 2000kg
- Weight: 705g


* Line load through cleat not to exceed 400kg (880lb)
